1280x1024 Thermal + 4MP 52X Optical Zoom Bi - Spectrum Hnyav Load High Precision Network PTZ Koob Yees Duab
|
Tus qauv |
SG - PTZ4052NIO2 -12T30180 |
SG - PTZ4052NIO2 -6T30180 |
||||
|
Thermal |
||||||
|
Sensor |
Cov Duab Sensor |
UNCOnted Vox Microbolometer |
UNCOnted Vox Microbolometer |
|||
|
Teeb meem |
1280 × 1024 |
640 × 512 |
||||
|
Pixel loj |
12μm |
12μm |
||||
|
Spectral ntau yam |
8 ~ 14μm |
8 ~ 14μm |
||||
|
Netd |
≤50MK @ 25 ℃, F # 1.0 |
≤50MK @ 25 ℃, F # 1.0 |
||||
|
Daim iab |
Focal ntev |
30 ~ 180mm Motor Lens |
30 ~ 180mm Motor Lens |
|||
|
Lub tsev txwv |
F1.0 ~ F1.4 |
F1.0 ~ F1.4 |
||||
|
Teb ntawm saib |
28.72 ° × 23.15 ° ~ 4.89 ° × 3.91 ° (w ~ t) |
14.59 ° × 11.69 ° ~ 2.44 ° × 1.96 ° (w ~ t) |
||||
|
Kho Qhov Muag |
6x |
6x |
||||
|
Digital Zoom |
4x |
8x |
||||
|
Kev Tiv Thaiv Qib |
IP66 waterproof rau lub khob thib 1 ntawm lens. |
|||||
|
Daim duab |
Kev nyuaj |
H.265 / H.264B / H.264M / H.264H / MJPEG |
||||
|
Ntawv thaij |
Jpeg |
|||||
|
Pseudo xim |
Kev Txhawb Nqa: Dawb Kub, Dub Kub, Hlau Liab, Zaj sawv 1, Fulgake, Zaj Tshos 2, Fusion, Amber, Arctic, Tint |
|||||
|
Dej |
Lub tseem ceeb dej: 25/1fps @ 1280 × 1024, 25/1fps @ 704 × 576 SUB - KUB: 25/1FPS @ 704 × 576, 25/1fps @ 352 × 288 |
|||||
|
Lub network |
Network Qaum Ua Si |
Ipv4, IPv, https, UDP, UDP, RTP, NTP, ITP, ICMP, SNTP, QOS, 802.1x, Bonjour |
||||
|
Kev sib tshuam |
Onvif, http API, SDK, GB28181 |
|||||
|
Max. Kev sib txua |
20 |
|||||
|
Kev txawj ntse |
Li qub |
Kev kuaj cov suab, kaw suab, IP chaw nyob tsis sib haum xeeb, kev cai nkag tsis raug cai, cia anomaly |
||||
|
IVS FUNCTIONS |
Txhawb cov ntse ua haujlwm:Dawm xyuas,Hla laj kab laj kab, kev nkag, Loitering nrhiav. |
|||||
|
Nrhiav Kom Tau Hluav Taws |
Ev |
|||||
|
Cov peev xwm cia |
Micro SD daim npav, txog 256g |
|||||
|
Rooj cavle |
||||||
|
Sensor |
Cov Duab Sensor |
1/8 1.8 "Sony Starvis zuj zus scan cmos |
||||
|
Zoo Pixels |
Kwv yees li. 4.17 Megapixel |
|||||
|
Daim iab |
Focal ntev |
15 hli ~ 775mm, 52x optical zoom |
||||
|
Lub tsev txwv |
F2.8 ~ F8.2 |
|||||
|
Teb ntawm saib |
H: 29.1 ° ~ 0.57 ° ~ 0.57 °, V: 16.7 ° ~ 0.32 ° ~ 0.32 ° ~ 33.2 ° ~ 0.00 ° ~ 0.66 ° ~ 0.66 ° |
|||||
|
Kaw kev deb |
1m ~ 10m (dav ~ tele) |
|||||
|
Zoom Ceev |
Kwv yees li. 7s (Optical dav ~ tele) |
|||||
|
Dori nrug (Tib neeg) |
Pom |
Xam pom |
Nco |
Txheeb xyuas |
||
|
10,808m |
4,289m |
2,162m |
1,081m |
|||
|
Daim duab |
Kev nyuaj |
H.265 / H.264 / H.264H / MJPEG |
||||
|
Streaming Muaj Peev Xwm |
3 ntws |
|||||
|
Teeb meem |
50Hz: 50fps @ 4MP (2688 × 1520); 50FPS @ 2MP (1920 × 1080) 60Hz: 60fps @ 4MP (2688 × 1520); 60fps @ 2MP (1920 × 1080) |
|||||
|
Tus lej me ntsis |
32Kbps ~ 16mbps |
|||||
|
Lub suab |
AAC / mp2l2 |
|||||
|
Lub network |
Network Qaum Ua Si |
Ipv4, IPv, https, UDP, UDP, RTP, NTP, ITP, ICMP, SNTP, QOS, 802.1x, Bonjour |
||||
|
API |
Onvif, http API, sdk |
|||||
|
Web browser |
Piv txwv li, ntug, Firefox, Chrome |
|||||
|
Tus siv |
Txog 20 cov neeg siv, 2 Qib: Tus Thawj Coj, Neeg Siv |
|||||
|
Chaw ntim khoom |
Micro sd / sdhc / sdxc daim npav (txog 1tb) ntug cia, FTP, NAS |
|||||
|
Multicast |
Ev |
|||||
|
Txheej xwm General |
Tsab ntawv tsa suab, Tamper, SD daim npav, network |
|||||
|
Ivs |
Tripwire, Hla lub laj kab laj, tso tseg cov khoom, kev tawm tsam, pawg neeg kwv yees, ploj qhov khoom, them tas los tau paub. |
|||||
|
Lub hom phiaj txawv |
Neeg / tsheb / lub nkoj xav tau |
|||||
|
NWS PIB KHAWV |
Ntau yam nrhiav kom pom cov qauv |
|||||
|
S / n piv txwv |
≥5DB (AGC tawm, qhov hnyav ntawm) |
|||||
|
Yam tsawg kawg nkaus teeb |
Xim: 0.01lux / f2.8; B / W: 0.001lux / F2.8 (AGC & AI - NRKE) |
|||||
|
Suab nrov txo |
2d / 3D / AI suab nrov |
|||||
|
Lub Hom Phiaj |
Pib, Aperture Prece Priatority, Ncig Saib Xyuas Qhov Tseem Ceeb, Tshaj Tawm Ua Ntej, Phau Ntawv |
|||||
|
Raug Them Nyiaj |
Ev |
|||||
|
Shutter Ceev |
1/1 ~ 1 / 30000s |
|||||
|
Txhos |
Ev |
|||||
|
Hlc |
Ev |
|||||
|
Wdr |
Txhawb nqa, 120dB |
|||||
|
Dawb Tshuav |
Nws pib, phau ntawv, sab nraud, sab nraum zoov, nyob sab nraum zoov, ntawm lub teeb, sodium, lub teeb txoj kev, ntuj, ib lub laub |
|||||
|
Hnub / Hmo |
Hluav Taws Xob, ICR (Pib / Los Ntawm Txhais Tes) |
|||||
|
Tsom hom |
Nws pib, phau ntawv, Semi pib, ceev pib, ceev semi pib, ib lub laub af |
|||||
|
Hauv Defog |
Ev |
|||||
|
Kho qhov muag |
Txhawb nqa, 750NM ~ 1100nm channel yog kho qhov muag |
|||||
|
Kub Kub Kub Kub Txo |
Ev |
|||||
|
Ntxeev |
Ev |
|||||
|
EIS |
Ev |
|||||
|
OIS (Kho duab duab stabilization) |
Txhawb (on / tawm) |
|||||
|
Digital Zoom |
16X |
|||||
|
Lauj kaub qaij |
||||||
|
Pan / Tilt ntau |
Lauj kaub: 360 ° Tig; Qaij: - 90 ° ~ + 90 ° |
|||||
|
YIAS CEEV |
Configurable, lauj kaub: 0.02 ° ~ 120 ° / s |
|||||
|
Qaij ceev |
Kev teeb tsa, YIAS: 0.02 ° ~ 80 ° / S |
|||||
|
Tso rau qhov tseeb |
0.01 ° |
|||||
|
Preset |
256 |
|||||
|
Kev xyuas teb chaws |
8, mus txog 32 presets ib ncig xyuas |
|||||
|
Luam luam |
5 |
|||||
|
Tus qauv |
5 |
|||||
|
Tshav ua si |
Preset / Ncig Saib / Scan / Txawv |
|||||
|
Teem sijhawm |
Preset / Ncig Saib / Scan / Txawv |
|||||
|
Lub Hwj Chim - Tawm Nco |
Ev |
|||||
|
Snap muab tso rau |
Ev |
|||||
|
Ib feem proportional p / t kom zoom |
Ev |
|||||
|
Rhaub / kiv cua |
Sib xyaw, pib / txhais tes |
|||||
|
Dai |
Kev sib xyaw, phau ntawv / teem sijhawm |
|||||
|
Kev sib tshuam |
||||||
|
Fais fab interface |
Txhawb nqa, gnd |
|||||
|
Ethernet |
1x rj45 (10 / 100Mbps tus kheej - Tsaws ethernet ports) |
|||||
|
Audio I / O |
1/1 (rau pom lub koob yees duab nkaus xwb) |
|||||
|
Tswb kuv / O |
2/1 |
|||||
|
RS485 |
1, Txhawb Pelco - D Raws Cai |
|||||
|
Nais phoo |
||||||
|
Dej |
IP 67, NEMA 4X |
|||||
|
Hwjchim |
DC36, raug 30W, max 120W |
|||||
|
Kev vaum |
<90%, tsis - condensing |
|||||
|
Tsev hauj lwm kub |
- 40 ℃ ~ + 70 ℃ / 40 ℉ ~ 158 ℉ |
|||||
|
Qhov loj me (L * W * H) |
368mm * 540mm * 355mm |
|||||
|
Qho hnyav |
Kwv yees li. 28Kg |
|||||
|
Povhwm |
Corrosion - Cov coating Couts Cov Qauv Txheej Txheem Koom Tes Nrog: ASTM B117 / ISO9227 (2000 teev) TVS 6000V, Surge tiv thaiv, voltage cov kev tiv thaiv kev tiv thaiv |
|||||
